Jozefina Lichtenegger |
With her vast knowledge of the workings of vacuum tubes, it was only natural that Jozefina Lichtenegger would expand the European Audio Team product line to include phono preamplifiers and even a vacuum tube integrated amplifier.
As with all EAT products, the engineering and build quality of these products is impeccable, and the visual design is every bit an example of Jozefina’s flair for the elegant.
All of the EAT amplification products come with attractive wooden side panels in choice of finishes and fine matte silver metal work.
Also on offer are EAT’s industry leading 300B and KT88 vacuum tubes. These vacuum tubes are manufactured under the most stringent quality control protocols in the industry. The EAT KT88 vacuum tubes are an excellent upgrade to the E-Glo I integrated amplifier.
Specifications
Output Power Per Channel: Triode – 18 watts, 4 and 8 Ohms
Ultralinear – 35 watts, 4 and 8 Ohms
Input Sensitivity: 500 mV
Input Impedance: 30k Ohms
Frequency Range: 10 – 50,000 Hz
Harmonic Distortion: 0.05% at 1k Hz, 5 watts
Signal To Noise: 95 dB
Inputs: 5 on RCA jacks
Tube Complement: 1 x 12AX7, 2 x 12AT7, 4 x KT88
Dimensions: 435 mm wide x 170 mm high x 485 mm deep
Weight: 26 kg
Available with piano black or macassar side panels
Retail Price: $12,999.00
Specifications
Voltage Gain Settings: Moving Magnet – 46 dB
Moving Coil 1 – 70 dB
Moving Coil 2 – 76 dB
Input Impedance: Moving Magnet – 47k Ohms
MC 1 – 10,20,40,80,150,300, 600, 1200 Ohms
MC 2 – 2,5,10,20,40,80,150, 300 Ohms
Moving Magnet Capacitance: 50,150,270,370,520,620,740,840 pF
Output Impedance: 150 Ohms
Signal To Noise: Moving Magnet – 80 dBV,
Moving Coil – 79 dBV
Available with piano black or macassar side panels
Retail Price: $8999.00
Specifications
Voltage Gain Settings: Moving Magnet – 45 dB
Moving Coil – 45, 50, 55, 65, 70 dB
Input Impedance: Moving Magnet – 47k Ohms
Moving Coil – 10, 25, 50, 75, 100, 1000 Ohms
Moving Magnet Capacitance: 50,100,150,200,270,320,420 pF
Output Impedance: 100 Ohms
Available with piano black or macassar side panels
Retail Price: $3599.00
Available Packaged With the EAT LPS Outboard Linear Power Supply
Retail Price: $4999.00
Specifications
Voltage Gain Settings: 40, 45, 50, 60, 65, 70 dB
Input Impedance: Low – 10, 18, 43, 75, 150, 300, 600, 1200 Ohms
High - 30, 36, 42, 47, 53, 59, 65, 75,000 Ohms
Moving Magnet Capacitance: 50, 150, 270, 370, 520, 620 pF
Output Impedance: 100 Ohms
Available with piano black or macassar side panels
Retail Price: $1699.00
Specifications
Input Power: 120 or 230 volts AC
Output Voltage: 1 × 15V/2A ± 0.05%, max noise 10uV
1 × 18V/1.5A ± 0.05%, max noise 1uV
Umbilical cable set included
Compatible with EAT C-Sharp, C-Major, E-Flat, Forte, Forte S, E-Glo S
Retail Price: $1699.00
Characteristics:
Plate dissipation (Max.): 40 W
Grid dissipation (Max.): 6 W
Cooling: By Radiation
Heater: Voltage: 6.3 V; Current: 1.6 A
Maximum ratings:
Anode voltage: 800 V
Screen grid voltage: 600 V
Va, g2: 600 V
Vgl: 200 V
Pa: 35 W
Pg2: 6 W
Pa + g2: 40 W
Ik: 230 mA
Vh -k: 200 V
Tbulb: 250 °C
| Retail Price: |
$3000.00 Per Matched Quad |
Valve Type: 300B Triode
Amplification Factor: 3.9
Filament Voltage: 5 Volts
Filament Current: 1.25 Amps
Size – Including Socket: 6.6 × 16 cm / 2.6 × 6.3 inch
Cathode: Oxide, Directly Heated
Maximum Anode Dissipation: 36 Watts
Transconductance: 5 mA/V
Max. DC Anode Voltage: 450 Volts
Valve Cooling : Radiation
Measured Value: 1.1 Amps
Retail Price: $1995.00 Per Matched Pair
 |
|
 |
Cool Damper in Black |
|
Cool Damper in Red |
The EAT Cool Damper device is a highly effective vibration absorbing and dissipating damper. The resulting benefit is reduced distortion from the tube circuit, as well as vastly reduced tendencies for the vacuum tube to operate in a microphonic manner. This improves sound quality with respect to providing more controlled and deeper bass, a cleaner sound stage, crisper and greater dynamic range, and better focus of the entire sound field.
The Cool Damper also reduces the operating temperature of the glass envelope of a vacuum tube by about 10%, which can appreciably extend the lifetime of the tube.
The Cool Damper is a consumer friendly product that is easy to install, and fabulously simple in design.
The Cool Damper is constructed of soft aluminum extrusion that has been coated with a special blended mix of Teflon and carbon composite PTFE. The Cool Dampers are finished with long-lasting anodic oxidation colors.
For flexible and easy use, the EAT Cool Damper uses six special carbon-Teflon composite V- profile strips that are adjustable and configurable to fit individual tube glass envelopes.
The EAT Cool Damper fits the following vacuum tube varieties:
12AT7: ECC81, 6201, E81CC, ECC801, B309, 6060, 6679, 7728, CV455, CV2016, CV8154, 12AU7: ECC82, E82CC, 6067, B339, 5814, 6189, 6680, 7730, CV491, CV8155, 12AX7: ECC83, E83CC, ECC803, 7025, 5751, 7058, 7729, 6681, CV492, CV8156, 6DJ8, ECC88, E88CC, 6922, EL84, EF86 and many others.
Available in black and red.
Retail Price: $35.00 Each
|
