Harmonic Technology offers a range of audio cable designs based on solid engineering and material science.

When Jim Wang founded Harmonic Technology in 1998, the hi-fi industry was just learning what was possible with respect to the cable product category advancing the quality of sound reproductions.  But from the very beginning he was a step ahead of just about everyone else and a true pioneer in the field.

Harmonic Technology was at the forefront of the move to OCC copper for its wire, and that step has evolved into their now patented OCC Single Crystal™ copper wire.  The special copper wire is produced with special manufacturing equipment that creates an artificial atmosphere that is completely devoid of oxygen and all other contaminants that could end up in the copper wire during production.  This process results in wire that is 99.999997% pure.

Copper wire of this purity has enhanced conductive properties.  Enhanced conductive properties are so desirable, and so beneficial to superior sound reproduction, that Harmonic Technology also uses their OCC Single Crystal™ copper in the manufacture of their cable connectors.

Harmonic Technology has also advanced the use of air-formed polyethylene as a dielectric material.  This particular dielectric material is effective in preventing oxidation of the copper conductor, and it also is effective at maintaining a constant reading of 2.25 Ohms of resistance when measured at any point in the cable.  This consistency of resistance is responsible for the excellent dynamic range and signal-to-noise measurements that can be achieved with Harmonic Technology cables.

Please note that for the do-it-yourselfer, Harmonic Technology wire is available in bulk lots so you can build your own cables.  Call or email us for details.

Osage Audio Products is pleased to offer the excellent Harmonic Technology line of hi-fi cables.  Very few companies in the industry have the reputation for excellent in product and service as that of Harmonic Technology.

We offer standard length and termination option Harmonic Technology products for sale through our Online Store and you can purchase custom length and configuration products by calling us at 573-696-3551 or you can email us.


Click on the category below to go directly to the Harmonic Technology product section of your choice:



ANALOG INTERCONNECT CABLES

Armour Link III

Harmonic Technology Armour Link III makes its debut in 2015 with a unique design concept and special conductor material – OCC Single Crystal Litz copper wire & Single Crystal OCC silver plated Litz copper wire.

The Armour Link III consists of one OCC Single Crystal Litz silver plated copper conductor and two OCC Single Crystal Litz copper conductors.  The conductors have a central polyethylene air tube and a spiral double-layer conductor core.  This configuration is covered with a micro porous Teflon® insulator.  This conductor material and cable structure helps reduce inductance, capacitance, and skin effect.

Technical Data

Details

RCA Terminations

XLR Terminations

Capacitance per foot

57 pF

57 pF

Inductance per foot

0.19 uH

0.19 uH

Resistance per foot

0.0049 Ohm

0.0049 Ohm

Retail Prices:

            1 Meter Pair With RCA Terminations:  $1300.00
            1 Meter Pair With XLR Terminations:  $1400.00

            Each Additional .5 Meter Length:  $400.00



Magic Link III

A perennial award winner, including The Absolute Sound Editor’s Choice Award every year since 2009, the Magic Link III uses a combination of OCC Single Crystalsilver and copper conductors, each individually insulated with highly flexible polyethylene and Teflon®.

The MAGIC Link III offers unparalleled performance at its price point, offering outstanding transparency, dynamic freedom, and resolved and clean bass articulation.  Smooth and extended treble response and a vibrant midrange are more reasons why the Magic Link III continues to win awards.

Technical Data

Details

RCA Terminations

XLR Terminations

Capacitance per foot

50 pF

64 pF

Inductance per foot

0.20 uH

0.34 uH

Resistance per foot

0.004 Ohm

0.003 Ohm

Retail Prices:

            1 Meter Pair With RCA Terminations:  $900.00
            1 Meter Pair With XLR Terminations:  $950.00

            Each Additional .5 Meter Length:  $300.00



Magic Link III RCA-To-RCA Phono Cable

Based on the multiple award winning Magic Link III analog interconnect cables, the Magic Link III Phono Cable also uses a combination of OCC Single Crystalsilver and copper conductors, each individually insulated with highly flexible polyethylene and Teflon®.

The MAGIC Link III Phono Cable offers unparalleled performance at its price point, offering outstanding transparency, dynamic freedom, and resolved and clean bass articulation.  Smooth and extended treble response and a vibrant midrange are more reasons why the Magic Link III Phono Cable could be the right choice for your system.

Technical Data

Capacitance per foot

50 pF

Inductance per foot

0.20 uH

Resistance per foot

0.004 Ohm

Retail Price For 1 Meter Cable:  $1000.00

Each Additional .5 Meter Length:  $300.00



Melody Link III

Utilizing Harmonic Technology’s OCC Single Crystal silver and copper conductors, the Melody Link III is a price-to-performance leader in analog interconnect cables.  The conductors are structured in pairs of solid and stranded types with triple shielding.

The result is a cable that preserves the clarity and tonal balance and color of recordings and that offers exceptional dynamics and balance.

Technical Data

Details

RCA Terminations

XLR Terminations

Capacitance per foot

40 pF

40 pF

Inductance per foot

0.48 uH

0.46 uH

Resistance per foot

0.008 Ohm

0.009 Ohm

Retail Prices:

            1 Meter Pair With RCA Terminations:  $600.00
            1 Meter Pair With XLR Terminations:  $650.00

            Each Additional .5 Meter Length:  $180.00



Melody Link III RCA-To-RCA Phono Cable

Constructed of Harmonic Technology’s OCC Single Crystal silver and copper conductors, the Melody Link III Phono Cable is a price-to-performance leader and an upgrade over most other phono cables on the market.  The conductors are structured in pairs of solid and stranded types with triple shielding.

The result is a phono cable that preserves the clarity and tonal balance and color of recordings and that offers exceptional dynamics and balance.

Technical Data

Capacitance per foot

40 pF

Inductance per foot

0.48 uH

Resistance per foot

0.008 Ohm

Retail Price For 1 Meter Cable:  $700.00

Each Additional .5 Meter Length:  $180.00



Truth Link III

Another performance leader at its price point, the Truth Link III is composed of Harmonic Technology’s OCC Single Crystal™ copper conductors and their Balanced Field Geometry™ technology.  Only the best insulation and multiple layer shielding are used in the construction of the cable.

The Truth Link III interconnect cable is especially well suited for smoothing out the sound of a system that tends toward brightness and grain in the treble region.  But in doing so the treble response is not reduced or pushed back in any way.

Technical Data

Details

RCA Terminations

XLR Terminations

Capacitance per foot

50 pF

47 pF

Inductance per foot

0.42 uH

0.50 uH

Resistance per foot

0.008 Ohm

0.009 Ohm

Retail Prices:

            1 Meter Pair With RCA Terminations:  $350.00
            1 Meter Pair With XLR Terminations:  $400.00

            Each Additional .5 Meter Length:  $120.00



Truth Link III RCA-To-RCA Phono Cable

Another performance leader at its price point, the Truth Link III Phono Cable is composed of Harmonic Technology’s OCC Single Crystal™ copper conductors and their Balanced Field Geometry™ technology.  Only the best insulation and multiple layer shielding are used in the construction of the cable.

The Truth Link III Phono Cable is especially well suited for smoothing out the sound of a system that tends toward brightness and grain in the treble region.  But in doing so the treble response is not reduced or pushed back in any way.

Technical Data

Capacitance per foot

50 pF

Inductance per foot

0.42 uH

Resistance per foot

0.008 Ohm

Retail Price For 1 Meter Cable:  $450.00

Each Additional .5 Meter Length:  $120.00



Harmony Link III

Harmonic Technology redefines what build and performance quality mean at a budge price with the Harmony Link III analog interconnect cables.  Using their patented OCC Single Crystal™ copper conductors and high quality shielding and insulation, the Harmony Link III delivers outstanding measured specifications as well as real high fidelity sound quality.

Technical Data

Details

RCA Terminations

XLR Terminations

Capacitance per foot

62 pF

60 pF

Inductance per foot

0.52 uH

0.49 uH

Resistance per foot

0.013 Ohm

0.011 Ohm

Retail Prices:

            1 Meter Pair With RCA Terminations:  $120.00
            1 Meter Pair With XLR Terminations:  $150.00

            Each Additional .5 Meter Length:  $40.00



LOUDSPEAKER CABLES

Pro-7 Reference Armour

The Pro-7 Reference Armour design features a combination of double layer OCC Single Crystal™ copper Litz and OCC Single Crystal™ silver-plated copper Litz conductors in a symmetrical quad configuration.

The conductors are insulated with micro porous Teflon® and the wire structure features a polyethylene central air tube.

This unique design and superior conductor material rewards the user with musical reproduction that offers superb and precise detail and dynamics and vivid holographic dimensionality.

Available with your choice of Harmonic Technology’s OCC Single Crystal™ copper banana plugs or spades.

Retail Prices:

            8 Foot Single Wire Pair:  $3500.00
            8 Foot Internal Bi-Wire Pair:  $3800.00

            Each Additional 1 Foot In Length:  $350.00
            Deduct for Each 1 Foot In Length Less than 8 Feet:  $300.00



Pro-9 Reference SE

Featuring improved geometry over the Pro-9 Reference, the Pro-9 Reference SE version speaker cable is constructed using Harmonic Technology’s OCC Single Crystal™ copper in a 9 gauge size.

Multiple high performance shield layers are used in the construction, as are highly flexible polyethylene and Teflon® insulating layers.  The Pro-9 Reference SE offers good flexibility for easy dressing of the cables.

The Pro-9 Reference SE loudspeaker cable is a true reference quality product that is at home in any high end hi-fi system.

Available with your choice of Harmonic Technology’s OCC Single Crystal™ copper banana plugs or spades.

Retail Prices:

            8 Foot Single Wire Pair:  $1700.00
            8 Foot Internal Bi-Wire Pair:  $1800.00
            8 Foot External Bi-Wire Pair:  $2200.00

            Each Additional 1 Foot In Length:  $250.00
            Deduct for Each 1 Foot In Length Less than 8 Feet:  $200.00



Pro-11 Reference II

Like all Harmonic Technology products, the Pro-11 Reference speaker cable uses their OCC Single Crystal™ copper conductors.  To make the 11 gauge conductor configuration of the Pro-11 Reference, eight subgroups of 20 to 24 gauge wire are covered with high quality polyethylene, polypropylene, and PVC insulation, wrapped with a Teflon®  tape.

The result is a loudspeaker cable that conveys all of the tonal balance and richness, as well as clarity and definition, of the recording.

Available with your choice of Harmonic Technology’s OCC Single Crystal™ copper banana plugs or spades.

Retail Prices:

            8 Foot Single Wire Pair:  $990.00

            Each Additional 1 Foot In Length:  $100.00



Pro-13 Reference II

The Pro-13 Reference II is constructed of nine subgroups of 20, 22, and 24 gauge OCC Single Crystal™ copper wire that is insulated with polyethylene, polypropylene, and PVB and wrapped with a Teflon® tape.  This design is very similar to that used in the original Pro-9 loudspeaker cable.

The Pro-13 Reference II is a lower cost alternative that allows entry into the world of high fidelity sound reproduction without sacrificing sound quality.

Available with your choice of Harmonic Technology’s OCC Single Crystal™ copper banana plugs or spades.

Retail Prices:

            8 Foot Single Wire Pair:  $800.00

            Each Additional 1 Foot In Length:  $80.00



Pro-11 Reference II Bi-Wire Jumper Cables

The perfect choice for use with loudspeakers that have bi-wire terminals in applications where you don’t want the expense of bi-wire cables, or you have limited space to dress the cable, the Pro-11 Reference II Jumpers are built from the same wire as the Pro-11 Reference II loudspeaker cables, using Harmonic Technology’s patented OCC Single Crystal™ copper wire.

The Pro-11 Reference II Bi-Wire Jumper Cables are 6 inches in length and are available with your choice of OCC Single Crystal™ copper spades or banana plugs.

Retail Price:  $300.00 Per Set



DIGITAL CABLES

Magic Digital Silver III

The Magic Digital Silver III is a 110 Ohm digital cable that utilizes Harmonic Technology’s patented OCC Single Crystal™ silver conductor, along with their proprietary Triple Shield™ construction, to produce a true reference quality digital interconnect.

The Magic Digital Silver III is the perfect choice for connecting any digital components, including re-clocking devices.  It offers striking transparency, resolution, and balance, and is sure to be an improvement for nearly any system.

Available with your choice of RCA or XLR connectors and priced per cable.

Technical Data

Details

RCA Terminations

XLR Terminations

Capacitance per foot

34 pF

36 pF

Inductance per foot

0.36 uH

0.42 uH

Resistance per foot

0.004 Ohm

0.003 Ohm

Retail Prices:

            1 Meter Cable With RCA Terminations:  $350.00
            1 Meter Cable With XLR Terminations:  $350.00

            Each Additional 1 Meter Length:  $200.00



Magic Digital Copper III

Like the Magic Digital Silver III, the Magic Digital Copper III is a reference grade 110 Ohm digital interconnect.  The Magic Digital Copper III uses the patented Harmonic Technology OCC Single Crystal™ copper conductor in an elaborately shielded design that features braided oxygen free copper, Cu-Mylar foil and conductive PVC.

This shielding design results in a transmitted noise floor that is so low that it is hard to measure.  The result is outstanding clarity, resolution, and sound staging, among other attributes.

Available with your choice of RCA or XLR connectors and priced per cable.

Technical Data

Details

RCA Terminations

XLR Terminations

Capacitance per foot

22 pF

21 pF

Inductance per foot

0.50 uH

0.42 uH

Resistance per foot

0.014 Ohm

0.013 Ohm

Retail Prices:

            1 Meter Cable With RCA Terminations:  $160.00
            1 Meter Cable With XLR Terminations:  $160.00

            Each Additional 1 Meter Length:  $70.00



Digital Silver III SPDIF

The Harmonic Technology Digital Silver III is a true end-to-end 75 Ohm digital coaxial cable.  It is constructed using Harmonic Technology’s patented OCC Single Crystal™ silver conductor and it features advanced shielding techniques in its construction.

The result is a digital coax that offers rich harmonics, superb clarity, and the lack of harshness and grain.

Available with your choice of RCA or BNC connectors and priced per cable.

Technical Data

Details

RCA Terminations

BNC Terminations

Capacitance per foot

16 pF

16 pF

Inductance per foot

0.51 uH

0.51 uH

Resistance per foot

0.015 Ohm

0.015 Ohm

Retail Prices:

            1 Meter Cable With RCA Terminations:  $220.00
            1 Meter Cable With BNC Terminations:  $220.00

            Each Additional 1 Meter Length:  $100.00



Digital Copper III SPDIF

The Harmonic Technology Digital Copper III is a true end-to-end 75 Ohm digital coaxial cable.  It is constructed using Harmonic Technology’s patented OCC Single Crystal™ copper conductor and it features advanced shielding techniques in its construction.

The Digital Copper III offers ample and well defined bass and smooth, rich harmonic structure reproduction.  Due to the proprietary shielding, the noise floor is vanishing low, leading to exceptional clarity and reproduction of the musical program.

Available with your choice of RCA or BNC connectors and priced per cable.

Technical Data

Details

RCA Terminations

BNC Terminations

Capacitance per foot

22 pF

22 pF

Inductance per foot

0.46 uH

0.46 uH

Resistance per foot

0.008 Ohm

0.008 Ohm

Retail Prices:

            1 Meter Cable With RCA Terminations:  $130.00
            1 Meter Cable With BNC Terminations:  $130.00

            Each Additional 1 Meter Length:  $50.00



USB-2 A-B Silver USB

The USB-2 A-B Silver USB cable features conductors made from Harmonic Technology’s patented OCC Single Crystal silver.  This cable also features custom designed connectors and shielding topology, designed to give this cable the lowest noise floor of any USB cable on the market.

Retail Prices:

            1.0 Meter Length:  $150.00
            1.5 Meter Length:  $200.00



USB-2 A-B Copper USB

The USB-2 A-B Copper USB cable has the shielding and connector innovations of the USB A-B Silver USB cable, but uses Harmonic Technology’s patented OCC Single Crystalcopper conductors rather than silver.

The result is a cable that is lower in price but still has the build quality and performance capabilities of all Harmonic Technology cables.

Retail Prices:

            1.0 Meter Length:  $80.00
            1.5 Meter Length:  $110.00



Magic Audio HDMI

The Magic Audio HDMI is a proprietary Harmonic Technology design employing oxygen free copper and advanced shielding.  The Magic Audio HDMI is especially suited for digital hi-fi audio applications.

It is capable of transmitting video images also, but this high speed HDMI is best suited for audio applications.

Retail Prices:

            0.7 Meter Length:  $199.00
            1.0 Meter Length:  $220.00
            1.5 Meter Length:  $249.00
            2.0 Meter Length:  $299.00
            3.0 Meter Length:  $375.00



HDMI HEAC

The Harmonic Technology HDMI HEAC cable is a versatile cable that is suitable for high speed, 3D, and Ethernet applications.  It is also rated for in-wall applications.

The HDMI HEAC is made from silver clad copper and is capable of operation at 10.2 Gbps speeds.  It supports 4k x 2k video resolution and DSLR image resolution.

Retail Prices:

            0.5 Meter Length:  $99.00
            1.0 Meter Length:  $119.00
            1.5 Meter Length:  $129.00
            2.0 Meter Length:  $139.00
            3.0 Meter Length:  $159.00
            5.0 Meter Length:  $199.00
            7.0 Meter Length:  $249.00
            10.0 Meter Length:  $400.00
            15.0 Meter Length:  $500.00



POWER CORDS

Magic Power III Special Edition

Following in the footsteps of multiple Golden Ear Awards from the The Absolute Sound for its predecessors, the Harmonic Technology Magic Power III Special Edition power cord improves on those previous designs to up the ante hi-fi power cord performance.

The Magic Power III Special Edition is designed to filter noise components across the frequency band, including DC voltage components using the proprietary Harmonic Technology Pure AC Module™ (ACM), which is built into the power cord.  This filtration leads to a lower noise floor in a hi-fi system.

Product Specifications

Conductors:

Total of 10 AWG

Material:

Single Crystal OCC silver power cord

Insulation:

UL/CL3 and Ethylene Propylene (PE) insulation

Power Rating:

Used for AC sources between 100 to 240 V

Connectors:

IEC 15 or 20 AMP

Wall Plug:

US/EU

Damage Threshold:

Maximum of 2400 W of peak power or peak current of 20 A at 110V or 10 A at 220V

Constant Load:

Maximum of 800 W

Retail Price For 1.5 Meter Length:  $3600.00

Each Additional .5 Meter Length:  $800.00



Fantasy Power III Special Edition

The Harmonic Technology Fantasy Power III Special Edition power cord is a 10AWG size with conductors made of their patented OCC Single Crystal™ copper.  This is the latest version of another family of Harmonic Technology power cords that have been perennial winners of Golden Ear Awards from the The Absolute Sound.

Like the Magic Power III Special Edition, the Fantasy Power III Special Edition features the proprietary Harmonic Technology Pure AC Module™ (ACM), which is built into the power cord.  This filtration leads to a lower noise floor in a hi-fi system.

Product Specifications

Conductors:

Total of 10 AWG

Material:

Single Crystal OCC copper power cord

Insulation:

UL/CL3 and Ethylene Propylene (PE) insulation

Power Rating:

Used for AC sources between 100 to 240 V

Connectors:

IEC 15 or 20 AMP

Wall Plug:

US/EU

Damage Threshold:

Maximum of 2400 W of peak power or peak current of 20 A at 110V or 10 A at 220V

Constant Load:

Maximum of 800 W

Retail Price For 1.5 Meter Length:  $1800.00

Each Additional .5 Meter Length:  $150.00



Magic Power III AC 10

The Harmonic Technology Magic Power III AC 10 power cord is a 10AWG size with conductors made of Harmonic Technology’s patented OCC Single Crystal™ silver.  The Magic Power III AC 10 also features connectors made of the same material, which have been gold plated to enhance conductivity.

Product Specifications

Conductors:

Total of 10 AWG

Material:

Single Crystal OCC silver power cord

Insulation:

UL/CL3 and Ethylene Propylene (PE) insulation

Power Rating:

Used for AC sources between 100 to 240 V

Connectors:

IEC 15 or 20 AMP

Wall Plug:

US/EU

Retail Price For 1.5 Meter Length:  $2300.00

Each Additional .5 Meter Length:  $800.00



Fantasy Power III AC 10

Harmonic Technology power cords have long set the standards for build quality and safety.  No other power cord for hi-fi applications in the price range of the
Fantasy Power III AC 10 offers a true 10 gauge power cord made of single crystal OCC copper, or one that provides as much insulation.

Available with either 15 amp or 20 amp IEC connectors, the Fantasy Power III AC 10 is a logical choice for high performance power without breaking the bank.

Product Specifications

Conductors:

Total of 10 AWG

Material:

Single Crystal OCC copper power cord

Insulation:

UL/CL3 and Ethylene Propylene (PE) insulation

Power Rating:

Used for AC sources between 100 to 240 V

Connectors:

IEC 15 or 20 AMP

Wall Plug:

US/EU

Retail Price For 1.5 Meter Length:  $550.00

Each Additional .5 Meter Length:  $80.00



Fantasy Power III AC 11

The Fantasy Power III AC 11 is based on the Fantasy Power III AC 10, but in an 11AWG conductor size that is particularly suited for most front end components and line stages.

Like the Fantasy Power III AC 10, it features both a foil shield and a braided shield for superior noise rejection and has conductors made of Harmonic Technology’s OCC Single Crystal™ copper.

Product Specifications

Conductors:

Total of 11 AWG

Material:

Single Crystal OCC copper power cord

Insulation:

UL/CL3 and Ethylene Propylene (PE) insulation

Power Rating:

Used for AC sources between 100 to 240 V

Connectors:

IEC 15 or 20 AMP

Wall Plug:

US/EU

Retail Price For 1.5 Meter Length:  $480.00

Each Additional .5 Meter Length:  $60.00



Please note that for the do-it-yourselfer, Harmonic Technology wire is available in bulk lots so you can build your own cables.  Call or email us for details.

Osage Audio Products is pleased to offer the excellent Harmonic Technology line of hi-fi cables.  Very few companies in the industry have the reputation for excellent in product and service as that of Harmonic Technology.

We offer standard length and termination option Harmonic Technology products for sale through our Online Store and you can purchase custom length and configuration products by calling us at 573-696-3551 or you can email us.


Osage Audio Products, LLC ∙ P.O. Box 232 ∙ Hallsville, MO  65255
  573-696-3551
www.osageaudio.com ∙ info@audiointelligent.com
2007-2017 All Rights Reserved.
