The name Wharfedale represents nearly a century of hi-fi innovation.

Gilbert Briggs ca. 1950

In 1932, Gilbert Briggs built his very first loudspeaker in the cellar of his home in Ilkley, Yorkshire, a sleepy little market town located in the valley of the river “Wharfe”; an area known to this day as ‘Wharfedale’.  This unlikely location would see the birth of a brand that was to become recognized all over the world, and one that is synonymous with quality in high fidelity reproduction.

Gilbert Briggs is still much admired and respected throughout the world for his pioneering work in hi-fi reproduction and his endless pursuit of better sound quality, which was driven by his love of live music.   Mr. Briggs has been referred to by many as the “father of hi-fi” for his pioneering work in the field.

By 1936, Mr. Briggs’ company had outgrown its small premises and moved to a larger factory in Bradford.  When the war came, the factory continued production, and during the second half of the war, the Wharfedale Wireless Works was commissioned to make transformers for Marconi.  Some 40,000 units were completed by an expert staff of just twenty people before the war finally came to an end.

In the post-WWII era, Wharfedale’s expertise in loudspeaker design, as well as their reputation, continued to grow.  Wharfedale remained on the leading edge of technological advancement during this period, and continued to grow their popularity in both the consumer and professional loudspeaker markets.

A view along Highfield Road in Idle, Bradford, West Yorkshire, home of Wharfedale's design studios.

Now, with more than 75 years of setting the standards for perfecting loudspeaker performance, the most advanced research and development program, and the most integrated and thorough manufacturing and quality control process in the industry, Wharfedale, in order to remain at the forefront of audio, now has a dedicated 1.5 million square foot manufacturing operation in which every single part and manufacturing step is performed in-house.  This makes the design of any new loudspeaker an acoustic engineer’s dream.  Instead of having to use off-the-shelf components from a catalog as most other purported ‘hi-fi’ companies choose to, Wharfedale is able to build a complete product, from engineering and design to parts manufacturing to assembly, to achieve a harmony in performance and balance.

Wharfedale offers a wide range of loudspeakers, including everything from home theater loudspeaker systems to audiophile-grade subwoofers, models that pay homage to the company’s heritage, to high performance bookshelf and floor standing models.

Wharfedale loudspeakers are not available for purchase through our Online Store.  They are available in our showrooms and can also be purchased by telephone.  Osage Audio Products is authorized to sell Wharfedale throughout the United States.

To learn more or to place an order, call us at 573-696-3551 or email us.  We are open late seven days a week.



Available Finishes

Piano Black
Piano White
Piano Walnut
Red Mahogany


Walnut
Black Ash
White Ash



OPEN BOX SPECIAL

Reva-2

Specifications

            General Description:  2-way bass reflex bookshelf speaker
            Tweeter:  25mm textile dome
            Mid/bass:  125mm glass fiber cone
            Sensitivity:  86dB (2.83V @ 1m)
            Recommended Amplifier Power:  20 – 80 watts
            Peak SPL:  96dB
            Nominal Impedance:  8 Ohms
            Minimum Impedance:  4.4 Ohms
            Frequency Response:   48 Hz – 20k Hz (+/-3dB)
            Bass Extension:  42 Hz (-6dB)
            Dimensions:  357mm high x 204mm wide x 275mm deep
            Net Weight:  7.8 kg each

OPEN BOX PRICE FOR CREDIT CARD PAYMENT - $600.00
OPEN BOX PRICE FOR CASH OR CHECK PAYMENT - $550.00



Denton Heritage 85th Anniversary Loudspeaker

Specifications

           General Description:  2-way bass reflex bookshelf speaker
           Tweeter:  1” textile dome
           Midrange:  6.55” woven Kevlar® cone
           Sensitivity:  88dB (2.83V @ 1m)
           Recommended Amplifier Power:  20 – 120 watts
           Peak SPL:  95dB
           Nominal Impedance:  4 Ohms
           Minimum Impedance:  3.8 Ohms
           Frequency Response:   45 Hz – 20k Hz (+/-3dB)
           Bass Extension:  40 Hz (-6dB)
           Dimensions:  340mm high x 240mm wide x 275mm deep
           Net Weight:  9.0 kg each
           Available in Walnut Veneer or Red Mahogany Veneer
           Grilles Included

Retail Price:  $899.00 Per Pair



Linton Heritage 85th Anniversary Loudspeaker




Specifications

           General Description:  3-way bass reflex bookshelf speaker
           Tweeter:  1” textile dome
           Midrange:  5” woven Kevlar® cone
           Woofer:  8” woven Kevlar® cone
           Sensitivity:  90dB (2.83V @ 1m)
           Recommended Amplifier Power:  25 – 250 watts
           Peak SPL:  110dB
           Nominal Impedance:  6 Ohms
           Minimum Impedance:  3.5 Ohms
           Frequency Response:   40 Hz – 20k Hz (+/-3dB)
           Bass Extension:  35 Hz (-6dB)
           Dimensions:  565mm high x 300mm wide x 330mm deep
           Net Weight:  18.4 kg each
           Available in Walnut Veneer or Red Mahogany Veneer
           Grilles Included

Retail Price:  $1198.00 Per Pair

Matching Stands:  $300.00 Per Pair



Elysian 2



Specifications

            General Description:  3-way bass reflex stand mount speaker
            Tweeter:  90mm textile Air Motion Transformer
            Midrange:  150mm coated glass fiber matrix cone
            Bass:  220mm coated glass fiber matrix cone
            Sensitivity:  89dB (2.83V @ 1m)
            Recommended Amplifier Power:  25 – 250 watts
            Nominal Impedance:  4 Ohms
            Frequency Response:   30 Hz – 22k Hz (+/-3dB)
            Dimensions:  700mm high x 334mm wide x 432mm deep
            Net Weight:  30.5 kg each
            Available in Piano Black and Piano Walnut

Retail Price:  $6995.00 Per Pair

Matching Stands in Piano Black or Piano Walnut:  $500.00 Per Pair



Elysian 4



Specifications

            General Description:  3-way bass reflex floor standing speaker
            Tweeter:  90mm textile Air Motion Transformer
            Midrange:  150mm coated glass fiber matrix cone
            Bass:  220mm coated glass fiber matrix cone
            Sensitivity:  92dB (2.83V @ 1m)
            Recommended Amplifier Power:  15 – 250 watts
            Nominal Impedance:  4 Ohms
            Frequency Response:   30 Hz – 22k Hz (+/-3dB)
            Dimensions:  1188mm high x 402mm wide x 432mm deep
            Net Weight:  49.5 kg each
            Available in Piano Black and Piano Walnut

Retail Price:  $9995.00 Per Pair



EVO4.1

Specifications

           General Description:  2-way bass reflex bookshelf speaker
           Tweeter:  30*60 Air Motion Transformer
           Mid/bass:  130mm woven Kevlar® cone
           Sensitivity:  87dB (2.83V @ 1m)
           Recommended Amplifier Power:  25 – 100 watts
           Peak SPL:  104dB
           Nominal Impedance:  6 Ohms
           Minimum Impedance:  3.5 Ohms
           Frequency Response:   64 Hz – 22k Hz (+/-3dB)
           Bass Extension:  55 Hz (-6dB)
           Dimensions:  335mm high x 210mm wide x 285mm deep
           Net Weight:  7.8 kg each
           Available in Walnut Veneer, Black Ash Veneer, and White Ash Veneer

Retail Price:  $699.00 Per Pair



EVO4.2

Specifications

           General Description:  3-way bass reflex bookshelf speaker
           Tweeter:  30*60 Air Motion Transformer
           Midrange:  50mm Soft Dome
           Bass:  130mm woven Kevlar® cone
           Sensitivity:  87dB (2.83V @ 1m)
           Recommended Amplifier Power:  25 – 120 watts
           Peak SPL:  105dB
           Nominal Impedance:  6 Ohms
           Minimum Impedance:  4 Ohms
           Frequency Response:   54 Hz – 22k Hz (+/-3dB)
           Bass Extension:  48 Hz (-6dB)
           Dimensions:  455mm high x 250mm wide x 340mm deep
           Net Weight:  13.4 kg each
           Available in Walnut Veneer, Black Ash Veneer, and White Ash Veneer

Retail Price:  $998.00 Per Pair



EVO4.3



Specifications

           General Description:  3-way bass reflex floor standing speaker
           Tweeter:  30*60 Air Motion Transformer
           Midrange:  50mm Soft Dome
           Bass:  130mm woven Kevlar® cone
           Sensitivity:  88dB (2.83V @ 1m)
           Recommended Amplifier Power:  25 – 150 watts
           Peak SPL:  105dB
           Nominal Impedance:  6 Ohms
           Minimum Impedance:  4 Ohms
           Frequency Response:   48 Hz – 22k Hz (+/-3dB)
           Bass Extension:  42 Hz (-6dB)
           Dimensions:  875mm high x 210mm wide x 285mm deep
           Net Weight:  22.8 kg each
           Available in Walnut Veneer, Black Ash Veneer, and White Ash Veneer

Retail Price:  $1598.00 Per Pair



EVO4.4



Specifications

           General Description:  3-way bass reflex floor standing speaker
           Tweeter:  30*60 Air Motion Transformer
           Midrange:  50mm Soft Dome
           Bass:   2x130mm woven Kevlar® cone
           Sensitivity:  89dB (2.83V @ 1m)
           Recommended Amplifier Power:  30 – 200 watts
           Peak SPL:  107dB
           Nominal Impedance:  6 Ohms
           Minimum Impedance:  4.3 Ohms
           Frequency Response:   48 Hz – 22k Hz (+/-3dB)
           Bass Extension:  38 Hz (-6dB)
           Dimensions:  1060mm high x 250mm wide x 340mm deep
           Net Weight:  25.6 kg each
           Available in Walnut Veneer, Black Ash Veneer, and White Ash Veneer

Retail Price:  $1998.00 Per Pair



EVO4.C

Specifications

           General Description:  3-way bass reflex home cinema center
           channel speaker
           Tweeter:  30*60 Air Motion Transformer
           Midrange:  50mm Soft Dome
           Bass:   2x150mm woven Kevlar® cone
           Sensitivity:  90dB (2.83V @ 1m)
           Recommended Amplifier Power:  25 – 150 watts
           Peak SPL:  108dB
           Nominal Impedance:  6 Ohms
           Minimum Impedance:  4.3 Ohms
           Frequency Response:   48 Hz – 22k Hz (+/-3dB)
           Bass Extension:  42 Hz (-6dB)
           Dimensions:  245mm high x 750mm wide x 340mm deep
           Net Weight:  15.8 kg each
           Available in Walnut Veneer, Black Ash Veneer, and White Ash Veneer

Retail Price:  $798.00 Each



EVO4.S

Specifications

           General Description:  3-way bass reflex home cinema surround speaker
           Tweeter:  30*60 Air Motion Transformer
           Mid/bass:   2x150mm woven Kevlar® cone
           Sensitivity:  88dB (2.83V @ 1m)
           Recommended Amplifier Power:  25 – 120 watts
           Peak SPL:  106dB
           Nominal Impedance: 6 Ohms
           Minimum Impedance:  3.9 Ohms
           Frequency Response:   70 Hz – 22k Hz (+/-3dB)
           Bass Extension:  65 Hz (-6dB)
           Dimensions:  245mm high x 400mm wide x 145mm deep
           Net Weight:  11.8 kg each
           Available in Walnut Veneer, Black Ash Veneer, and White Ash Veneer

Retail Price:  $1598.00 Per Pair



WH-D8 Powered Subwoofer

Specifications

            General Description:  Powered reflex loaded subwoofer featuring phase
                                             inversion, low pass filter slope adjustment, auto on/off
            Drive Units: 1 x 200mm long throw cone
            Frequency Response:  30 Hz – 200 Hz (+/-3dB)
            Bass Extension:  30Hz
            Amplifier Power Output:  70 watts
            Peak Power Output: 150 watts
            Line Input Sensitivity:  200mV at maximum output
            Crossover Range: 40 Hz – 150 Hz
            Inputs:  Stereo – 2 x RCA; Mono – LFE, RCA Phono
            Input Impedance: Line In – 20k Ohms; LFE – 5 Ohms
            Signal-to-Noise Ratio:   ≧86dB
            Peak SPL: 110dB
            Dimensions:  330mm high x 268mm wide x 327mm deep
            Net Weight: 8.6 kg

Retail Price:  $399.00 Each



WH-D10 Powered Subwoofer

Specifications

            General Description:  Powered dynamic drive IB subwoofer featuring phase
                                             inversion, high pass and low pass filter slope
                                             adjustment, auto on/off
            Drive Units: 1 x 250mm long throw cone
            Frequency Response:  35 Hz – 150 Hz (+/-3dB)
            Bass Extension:  35Hz
            Amplifier Power Output:  150 watts
            Peak Power Output: 300 watts
            Line Input Sensitivity:  100mV at maximum output
            Crossover Range: 30 Hz – 150 Hz
            Inputs:  Stereo – 2 x RCA; Mono – LFE, RCA Phono
            Input Impedance: Line In – 10k Ohms; LFE – 5 Ohms
            Signal-to-Noise Ratio:   ≧85dB
            Peak SPL: 110dB
            Dimensions:  363mm high x 333mm wide x 372mm deep
            Net Weight: 16.5 kg

Retail Price:  $499.00 Each



SW-10 Powered Subwoofer

Specifications

            General Description:  Powered subwoofer featuring phase
                                             inversion, auto on/off
            Drive Units: 1 x 250mm long throw cone
            Frequency Response:  30 Hz – 150 Hz (+/-3dB)
            Bass Extension:  30Hz
            Amplifier Power Output:  200 watts
            Peak Power Output: 350 watts
            Line Input Sensitivity:  200mV at maximum output
            Crossover Range: 30 Hz – 150 Hz
            Inputs:  Stereo – 2 x RCA; Mono – LFE, RCA Phono
            Input Impedance: Line In – 10k Ohms; LFE – 5 Ohms
            Signal-to-Noise Ratio:   ≧85dB
            Peak SPL: 110dB
            Dimensions:  416mm high x 336mm wide x 366mm deep
            Net Weight: 15 kg

Retail Price:  $599.00 Each



SW-12 Powered Subwoofer

Specifications

            General Description:  Powered dynamic drive IB subwoofer featuring
                                             phase inversion, auto on/off
            Drive Units: 1 x 300mm long throw cone
            Frequency Response:  35 Hz – 120 Hz (+/-3dB)
            Bass Extension:  35Hz
            Amplifier Power Output:  300 watts
            Peak Power Output: 450 watts
            Line Input Sensitivity:  200mV at maximum output
            Crossover Range: 30 Hz – 150 Hz
            Inputs:  Stereo – 2 x RCA; Mono – LFE, RCA Phono
            Input Impedance: Line In – 10k Ohms; LFE – 5 Ohms
            Signal-to-Noise Ratio:   ≧85dB
            Peak SPL: 110dB
            Dimensions:  488mm high x 395mm wide x 442mm deep
            Net Weight: 22.1 kg

Retail Price:  $699.00 Each



SW-15 Powered Subwoofer

Specifications

            General Description:  Powered dynamic drive IB subwoofer featuring
                                             phase inversion, auto on/off
            Drive Units: 1 x 380mm long throw cone
            Frequency Response:  30 Hz – 120 Hz (+/-3dB)
            Bass Extension:  30Hz
            Amplifier Power Output:  400 watts
            Peak Power Output: 750 watts
            Line Input Sensitivity:  200mV at maximum output
            Crossover Range: 30 Hz – 150 Hz
            Inputs:  Stereo – 2 x RCA; Mono – LFE, RCA Phono
            Input Impedance: Line In – 10k Ohms; LFE – 5 Ohms
            Signal-to-Noise Ratio:   ≧85dB
            Peak SPL: 124dB
            Dimensions:  598mm high x 500mm wide x 540mm deep
            Net Weight: 27 kg

Retail Price:  $899.00 Each
